Self Propelled Reaper

• Capacity
• 0.3-0.5 hectare/hour (varies with crop and condition)

• Color
• Red & White

• Dimension (L*W*H)
• 1900 x 850 x 1100 mm (Approx)

• Disc Diameter
• Not Applicable (uses reaper cutter bar)

• Drive Type
• Gear Drive

• Engine Oil Capacity
• 0.6 Liters

• Engine Type
• Other, 4-stroke, Air-cooled

• Features
• Compact design, Easy operation, Adjustable cutting width

• Fuel Tank Capacity
• 3.6 Liters

• General Use
• Harvesting various crops including paddy, wheat, and barley

• Machine Speed
• 2-5 km/h

• Material
• Other, Heavy Duty Steel & Alloy

• Noise Level
• 88 dB (Aprox.)

• Power
• 5.5 HP

• Power Source
• other, Petrol / Gasoline

• Product Type
• Mini Harvester / Reaper

• Production Output
• Up to 0.5 hectare/hr

• Shape
• Rectangular body with front-mounted cutter bar

• Start Method
• Other, Recoil/Manual Start

• Tool Type
• Crop Reaper

• Transmission Type
• Other, Belt and Gear Driven

• Type
• Other, Self Propelled Reaper

• Usage & Applications
• Harvesting paddy, wheat, barley and similar grain crops

• Weight (kg)
• Around 300 kg

• Capacity
• 0.3-0.5 ha/hour

• Color
• Red & White

• Dimension (L*W*H)
• 2170 x 880 x 1140 mm

• Drive Type
• Gear Drive

• Engine Oil Capacity
• 0.6 L

• Engine Type
• Other, Air-cooled, 4-stroke single cylinder

• Features
• Lightweight design, easy maneuverability, efficient reaping, low maintenance, foldable handles

• Fuel Tank Capacity
• 3.6 L

• General Use
• Harvesting crops such as paddy, wheat, soya bean, and reed

• Machine Speed
• 2-6 km/h

• Material
• Other, Reinforced Steel frame and body

• Noise Level
• Low

• Power
• 4.05 kW (5.5 HP)

• Power Source
• other, Petrol Engine

• Product Type
• Agricultural Machinery

• Production Output
• Up to 0.5 hectare per hour

• Shape
• Rectangular base with extended reaping unit

• Start Method
• Other, Recoil Start

• Tool Type
• Reaper

• Transmission Type
• Other, Gear Transmission

• Type
• Other, Self Propelled Reaper

• Usage & Applications
• Ideal for small and medium farms, suitable for paddy, wheat, barley, oats, and grass cutting

• Weight (kg)
• 185 kg

• Capacity
• 0.3-0.5 hectares/hour

• Color
• Red and White

• Dimension (L*W*H)
• 2600 x 1680 x 1050 mm

• Drive Type
• Gear Drive

• Engine Oil Capacity
• 1.75 Litres

• Engine Type
• Other, Single Cylinder, 4-stroke, Air-cooled

• Features
• Compact design, easy to operate, suitable for small land holdings

• Fuel Tank Capacity
• 5.5 Litres

• General Use
• Reaping and harvesting short crops like wheat, rice, oats, barley, etc.

• Machine Speed
• 0.38-1.2 m/sec

• Material
• Other, MS (Mild Steel) and Other Alloys

• Noise Level
• Low

• Power
• 12 HP

• Power Source
• other, Diesel Engine

• Product Type
• Reaper Machine

• Production Output
• 3-5 tons/hour

• Shape
• Rectangular/Irregular as per reaper tool assembly

• Start Method
• Other, Manual Cranking

• Tool Type
• Agricultural Reaper

• Transmission Type
• Other, Gear Transmission

• Type
• Other, Self Propelled Reaper

• Usage & Applications
• Used for reaping short crops in agricultural fields

• Weight (kg)
• 524 kg

• Capacity
• 0.4-0.5 ha/hr

• Color
• Red & White

• Dimension (L*W*H)
• 2450 x 1350 x 1200 mm

• Drive Type
• Gear Drive

• Engine Oil Capacity
• 1.65 L

• Engine Type
• Other, Diesel, Single Cylinder, 4-Stroke, Air Cooled

• Features
• High Efficiency, Low Fuel Consumption, Easy Maneuverability, Adjustable Cutting Height, Easy Maintenance

• Fuel Tank Capacity
• 5.5 L

• General Use
• Self Propelled Reaping of Paddy, Wheat, and Other Crops

• Machine Speed
• 2.3 - 4.45 km/h

• Material
• Other, Mild Steel & Alloy Components

• Power
• 6.3 HP / 4.6 KW

• Power Source
• other, Diesel Engine

• Product Type
• Self Propelled Agricultural Reaper

• Production Output
• 1.6-2.2 acre/day

• Shape
• Rectangular Body with Crop Reaping Header

• Start Method
• Other, Manual/Recoil Start

• Tool Type
• Crop Reaper

• Transmission Type
• Other, Gear Transmission

• Type
• Other, Self Propelled Reaper

• Usage & Applications
• Harvesting/Reaping of Paddy, Wheat, and Other Grain Crops

• Weight (kg)
• 340 kg
